Product Description
Handheld fiber laser marking machine adopts advanced laser technology to achieve fast and high precision marking. Highly integrated design with small and lightweight body and removable battery design for unlimited use and improved work efficiency. The handheld laser marking equipment has a wider range of uses and greater flexibility to meet customers' daily needs
Touch screen design, users can operate directly within the system software.
The machine is lightweight and small in size, making it easy to carry and operate. Suitable for operation in many environments.
The small handheld fibre laser marking machine with battery model has the following features: Portability: these types of laser marking machines are compact in design, lightweight and easy to carry, allowing them to be moved and carried around easily. Its portable battery power makes it more suitable for various working scenarios. Flexibility: The handheld design makes it possible for the operator to move the laser head freely to achieve flexible marking positions and angles for workpieces of different shapes and sizes. High precision: fibre laser marking machines use laser beams for marking with high precision and detailed marking effects. They can achieve high-resolution, high-definition marking and are suitable for applications that require precise marking and patterning. High Efficiency: Fibre laser marking machines offer fast marking speeds and high working efficiency. They enable a fast marking process with a long service life and stable performance. LOW MAINTENANCE COST: Fibre laser marking machines usually use solid-state lasers, which have a long service life and stable performance. The machines are maintenance free
Main configuration
Machine parameters
| Parameter table | |
| laser | Fiber laser generator |
| Output power | 8W,20W,25W,30W |
| Marking range | 70x70mm,100x100mm (Optional) |
| Deflection seismoscope | High-precision two-dimension scanning system |
| Laser wavelength | 1064mm |
| Marking speed | <7000mm/s |
| Master control | Integrated motherboard, 8-inch capacitance,full-fit screen |
| Operating system | Linux system |
| Marking line type | Dot-matrix and vector all-in-one machine |
| Line width | 0.03mm |
| Repetitive positioning accuracy | 0.01mm |
| Positioning method | Red light positioning and focusing |
| Number of engraved character lines | Any line within the valid marking range |
| Printing speed | 800 characters (related to material and printing content) |
| Font | Chinese and English, digital, traditional Chinese and other standard font |
| File format | BMP,DXF,HPGL,JPEG,PLT |
| Bar code | CODE39,CODE128,CODE126. QR |
| Source | 110V/220V AC.lithium cell(216wh) |
| Overall power consumption | 145-250W |
| Operating temperature of the whole machine | 0-40° |
| Total Weight | 8KG |
Handheld Compact and lightweight, weighing only 6.8kg: Hand-held for flexible operation;
Power supply design 220V mains version: plug-and-play, easy and Fast; . lithium battery version: battery removable design, charging mode: offline or built-in; With the backup battery, you can use it forever.
Touch screen design 8-inch fully bonded LCD screen, one-button trigger, multi-purpose, hardware diversity and compatibility;
Configuration Linux system Adopt 8-core processor, configure security level, high performance and stable response.
Machine Display
1. Collect all accessories and spare parts one by one according to the order list, and double check all parts again to make sure all parts are included.
2. Our packaging standards:
+ thick cling film
+ six-sided pearl cotton
+ High strength wooden box
+ Pack the belt and then secure the machine to ensure the machine is safe during transport.
3. Paste the shipping mark to ensure that the buyer can easily identify the correct machine
4. A safety sign can be used to remind the transporter to keep our equipment in the course of transportation.
Our Service：
| 1 | Software is on update for free whole life. |
| 2 | Main parts be changed free of charge if there is any problem during the warranty period. |
| 3 | We will provide the consumable parts at an agency price. |
| 4 | We have user manual instruction and videos for software Installation, operation and machine's using and maintenance. |
| 5 | We will supply 24 hours online after service, and free technical support. |
| 6 | We debug the machine before shipment and carry out 12 hours working test to ensure the quality of the machine. |
| 7 | We offer the service, from you got the machine, including how to install the machine, how to use machine, how to let machine work, and so on. |
