Product Description
Features:
1.Small all-in-one appearance design, easy to carry
2.Wide range of applications, can mark metal materials and some non-metal materials
3.Low machine running cost
4.Easy transportation, low shipping cost
5.Genuine JCZ control board, stable performance
6.Perfect for DIY customers and shopping mall item marking
Configuration:
Machine Configuration:
Laser: RAYCUS/MAX/JPT laser can be selected. The machine can be configured 20W 30W 50W 60W power
Scanners: the use of SINO-GLAVO / HANS scanners, scanners with dual red light to assist focusing
Field mirror: high quality field mirror, 75-200mm working area can be selected.
Control board: BJJCZ genuine board and EZCAD2 software used together, good user interface
Machine size：
Machine Reference Parameters:
| Model | RF-F-20W | RF-F-25W |
| Laser output power | 20W | 25W |
| Laser source band | MAX | |
| Laser wavelength | 1064nm | |
| Laser beam quality | <1.5 | |
| Max pulse energy(mj) | 0.7 | 0.6 |
| Pulse duration(ns) | 90±10@27KHZ | 100±20@40KHZ |
| Pulse repetition rate range(KHZ) | 27-60 | 40-60 |
| Min. Character size | 0.2mm | |
| Repetition Accuracy | <8μrad | |
| Power consumption | 80W | 110W |
| Cooling type | Air cooling | |
| Marking area | 70*70-150*150mm | |
| Max working speed | 8000mm/s | |
| Laser spot (110x110) | 25.4μm | |
| Graphic Format Supported | AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP | |
| Mode of Operation | Pulsed | |
| Certification | CE | |
| Warranty | 2 years | |
| Supply voltage | AC110V 60HZ / AC220V 50HZ | |
| Focus type | Double red light | |
Optional accessories
Sample Show
Packing and Shipping
1.Colleet all accessories and spareone by one according to the orderlist, and double check all partsagain to make sure all parts areincluded.
2.Our packaging standarts:
+thick cling film
+six-sided pearl cotton
+High strength paper box
+Pack the helt and then secure themachine to ensure the machine issafe during transport.
3. Paste the shipping mark toensure that the buyer can easilyidentify the correct machine
4.A safety sign can be used toremind the transporter to keepour equipmentin the course oftransportation.
We will give away the following products for free：
| 1 | Inner Hexagon |
| 2 | Foot Switch |
| 3 | Power Cable |
| 4 | USB Flash Drive |
| 5 | Goggles |
| 6 | 60CM Ruler |
| 7 | Laser Inspect Report |
Shipping list
| 1 Set Fiber Laser Marking Machine |
| 1 Pcs Inner Hexagon |
| 1 Pcs Foot Switch |
| 1 Pcs Power Cable |
| 1 Pcs USB Flash Drive |
| 1 Pcs Goggles |
| 1 Pcs 60CM Ruler |
| 1 Pcs Laser Inspect Report |
Our Service
| 1 | Software is on update for free whole life. |
| 2 | Main parts be changed free of charge if there is any problem during the warranty period. |
| 3 | We will provide the consumable parts at an agency price. |
| 4 | We have user manual instruction and videos for software Installation, operation and machine's using and maintenance. |
| 5 | We will supply 24 hours online after service, and free technical support. |
| 6 | We debug the machine before shipment and carry out 12 hours working test to ensure the quality of the machine. |
| 7 | We offer the service, from you got the machine, including how to install the machine, how to use machine, how to let machine work, and so on. |
