| Quantity: | |
|---|---|
Product Description
Machine Features:
Main Application:
metal materials, stainless steel, carbon steel, copper, alloy, galvanized sheet, iron, aluminum, alloy metals.
Applicable industries:
Metal surface rust removal; surface paint removal treatment; surface oil, stain, dirt cleaning; surface coating, coating removal. Weld surface pretreatment. Treatment of dust and attachments on the surface of stone statues. Rubber mold residue cleaning. Remove oil stains, stains, coatings, platings, oxide layers, paints, welds, etc. attached to the surface of objects.
Cleaning Gun
Small size, light weight, with protective knob
Cleaning width can reach 300mm
Multi language optional
Support English, Japanese, Russian, Korean etc, can be customized.
Optional cleaning width
User can choose it according to the work piece cleaning area
| Photos | Description |
|
| Famous brand 1000W 1500W 2000W laser source
Famous brands, quality assurance. Optional brand：RAYCUS or MAX or JPT
|
|
| Fiber laser line
Generally the longer the length, the more serious the laser energy loss, our default is 9 meters.
|
|
| Handheld head
- High quality copper nozzle - Integrated gas protection system |
|
| Touch screen panel
Adjust and change laser power, parameters, laser mode, laser parameters
|
|
| Control System
|
|
| Industrial chiller
Intelligently and accurately control the temperature of the laser and the handheld swing head. |
We have JPT MAX RAYCUS laser source:
Machine Reference Parameters:
| Model | ES-1000CL | ES-1500CL | ES-2000CL |
| Control panel | Touch screen | Touch screen | Touch screen |
| Laser power | 1000W | 1500W | 2000W |
| Laser type | CW Fiber laser | CW Fiber laser | CW Fiber laser |
| Protective gas | Inert gas | Inert gas | Inert gas |
| Line length | 5~9 meter | 5~9 meter | 5~9 meter |
| Cleaning width | 0~300mm | 0~300mm | 0~300mm |
| Machine power supply | 220V | 220V | 220V / 380V |
| Machine cooling system | industrial water chiller | industrial water chiller | industrial water chiller |
| Machine weight | 180KG | 200KG | 220KG |
| Machine power | 4KW | 5.5KW | 7KW |
| Warranty | 24 month | 24 month | 24 month |
Samples:
Packing and Shipping:
1. Collect all accessories and spare parts one by one according to the order list, and double check all parts again to make sure all parts are included.
2. Our packaging standards:
+ thick cling film
+ six-sided pearl cotton
+ High strength wooden box
+ Pack the belt and then secure the machine to ensure the machine is safe during transport.
3. Paste the shipping mark to ensure that the buyer can easily identify the correct machine
4. A safety sign can be used to remind the transporter to keep our equipment in the course of transportation.
| 1 | Software is on update for free whole life. |
| 2 | Main parts be changed free of charge if there is any problem during the warranty period. |
| 3 | We will provide the consumable parts at an agency price. |
| 4 | We have user manual instruction and videos for software Installation, operation and machine's using and maintenance. |
| 5 | We will supply 24 hours online after service, and free technical support. |
| 6 | We debug the machine before shipment and carry out 12 hours working test to ensure the quality of the machine. |
| 7 | We offer the service, from you got the machine, including how to install the machine, how to use machine, how to let machine work, and so on. |
