Product Description
CO2 1310 300W Mixed Metal Non-Metal Cutting Machine
The 1310 Mixed CO2 Cutting Machine uses a CO2 laser source for cutting metals and non-metals. The machine can be set up with two laser heads, one for cutting metal and one for cutting and engraving non-metal.
The machine can cut 0-4mm metal and 0-30mm non-metal, such as acrylic, wood, Density board, and so on.
The working area of the machine support 1310,1390,1410 The power of the machine can be customized according to the need.
Metal cutting Thick material cutting
Metal cutting and thick acrylic wood cutting
Machine Advantage:
Cutting of metallic and non-metallic materials Stable and efficient metal-following cutting system High efficiency cooling system, industrial chiller CW6000 Preferred high-power laser, stable quality
Specification
Configurations
Specialised laser cutting head for metal cutting with high precision and long service life. At the same time it can be used for cutting thick non-metallic materials, acrylic, wood, etc. Two laser heads can be installed for the machine, one for metal and post non-metallic material cutting, and one for fine engraving non-metallic materials.
Different brands of laser tubes to choose from, stable working condition of laser tubes, worldwide warranty
Industrial chiller with constant temperature to ensure smooth operation of the machine
Product Parameter
| Focus lens | Imported ZnSe |
| Max moving speed | 0-40000mm/min |
| Laser energy control | 1-100% set by hand or software |
| Motorized up and down worktable | Yes |
| Power | 300W |
| Locating precision | <0.01mm |
| Min shaping character | Letter 1mm, Chinese 2mm |
| Operating temperature | -5ºC-35ºC |
| Resolution ratio | 4500dpi |
| Control program | RDCAM(LASERWORK) |
| Data transfer interface | USB |
| System environment | Win7/8/10/11 |
| Cooling way | Water chiller with protection system |
| Graphic format supported | The file which CorelDraw, Photoshop, can identify |
| Compatible software | CorelDraw, AutoCAD |
| Cutting thickness | 0-20mm (depends on different materials) |
| Voltage | AC110V/220V±10% 50HZ/60HZ |
Samples:
Packaging
Collect all accessories and spare parts one by one according to the order list and double-check all parts again to make sure that all parts are included.
Our packaging standards
+ thick cling film
+Six-sided pearl cotton
+ high strength wooden crates
+Packing tape to fix the machine to ensure the safety of the machine during transport.
Posting of shipping marks ensures buyers can easily identify the correct machine.
Posting security markings will remind the transporter to take proper care of our equipment.
Company
LIAOCHENG RAY FINE TECHNOLOGY CO, LTD was established in 2009, one special supplier of CNC laserequipment combined with produce,research and sales .Rayfine products covered: laser cutting machine,lasermarking machine and CNC router etc. Our CNC laser products has been sold to more than 100 countries otworldwide.such as Europe,America,south AfricaJapan,Korea,And enjoyed good reputation.RAYFINE has an special technical research team which can custom made the equipment according customersworking requirement.And supply all aspects technical service for customers.RAYFINE keeps strict compliance with the purchase channels, thigh-quality products accessories, strict production process and assessment criteria. Each equipment will be under full quality inspection before send out
