Product Description
Machine Features:
1.Can engrave and cut any non-metallic materials
2.Ruida controller and software easy study and operation
3.Linear square guide rails with high precision
4.Heavy duty machine body with good rigidity
5.Industry wheels single wheels bear weight up to 200kg. Stable and quiet.
6.3phase stepping motor drive higher precision low noise.
Machine details:
Ruida 6445s
*3.5 inch Screen *More Function keys on panel than 6442 *Multi-Language *Software RDworks V8
Door Protection System
Double sensor more safe
The laser cannot work when the door is opened, which better protects the safety of the staff at work
Front and back access door
The front and back access doorcan be opened, so that it is very convenient for processing longer materials.
Workbench
Aluminium blade worktable: Suitable for hard and large materials, such as acryl-ic、wood act.
Honeycomb table: Honeycomb table for small and soft materials.
LINEAR GUIDE RAILS
* Rugged and durable
* Low running resistance
* Can effectively improve work efficiency
* Low environmental requirements
* Works in harsh environments
* Low friction
Industrial water Chiller CW-3000 CW-5000 CW-5200
Front and rear feed ports
Others: No front and rear feedopenings
Our machine: Switchable and fully enclosed front and rear feed ports
Three major windows
Others: Single small window
Our machine: Three large windows more easy and comfortable to check the machine working condition
Machine configuration:
Sample Show:
Machine Reference Parameters:
| Model | RF-1390 |
| Laser source | RECI |
| Laser type | CO2 |
| Laser tube | Glass tube |
| Laser power | 75W/80W/90W/100W/130W/150W |
| Cutting depth | 0~30mm(non metal) |
| Control software | RUIDA |
| Control system | Windows |
| Working table | Aluminum knife table/Honeycomb table |
| Certification | CE |
| Operating voltage | AC220V 50HZ/AC110V 60HZ |
| Cooling type | Water chiller CW5200 or CW3000 |
| Min shaping character | Character: 1.5*1.5mm Letter: 0.7*0.7mm |
| Data transfer interface | USB |
| Operating temperature | -5℃-35℃ |
| Resolution ratio | 4500dpi |
| Graphic format supported | The file which Corel Draw, Photo shop, Auto-CAD can identify |
| Color separation | Separation of Cutting up to 256 colors |
| Compatible software | Corel Draw, Auto-CAD |
| Auto focus | optional |
| Packing | Plywood case |
Optional accessories：
Packing and Shipping
1. Ensure each part of the machine is clean and tidy before packaging;
2. Each accessory is wrapped in a recyclable plastic bag, then wrapped in cardboard;
3. Place the machine neatly (like a cube as much as possible) and add a thicker foam to the corners that are easy to bump;
4. Packing in wooden cases of suitable export standard plywood( fill the corners with recyclable plastic foam),then seal the case and fasten it with high quality stainless steel nails and steel straps.
5. Then seal the case and fasten it with high quality stainless steel nails and steel straps;
6. We will write the corresponding shipping marks on the cases according to the customer's requirements;
7. Print or spray paint safety sign in wooden box.
We will give away the following products for free：
Our Service
| 1 | Software is on update for free whole life. |
| 2 | Main parts be changed free of charge if there is any problem during the warranty period. |
| 3 | We will provide the consumable parts at an agency price. |
| 4 | We have user manual instruction and videos for software Installation, operation and machine's using and maintenance. |
| 5 | We will supply 24 hours online after service, and free technical support. |
| 6 | We debug the machine before shipment and carry out 12 hours working test to ensure the quality of the machine. |
| 7 | We offer the service, from you got the machine, including how to install the machine, how to use machine, how to let machine work, and so on. |
